HOT SALE! JMC 4*2 LHD diesel engine refrigerated minivan for sale, 2021s good price JMC cold refrigerated minibus for sale
Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc. More information, please feel free to contact with Ms. Anita.
overall dimension(L*W*H): 5652*1972*2450mm
Refrigerated van box dimension(L*W*H): 2800*1610*1350mm
The device of JMC refrigerated minivan as below.
Wheelbase: 3570mm
Engine: JMC JX493ZLQ6 diesel 115hp engine
tires specification: 225/65R16C
remark: power steering, air conditioner, electric door and windows, ABS
And the cold room box body dimension (L*W*H) of this JMC teshun diesel refrigerated minivan is 2800×1610×1350 (mm); while the overall dimension (L*W*H) of this JMC refrigerated truck is 5652×1972×2450 (mm). Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. Baseboard adopts anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. double rear door opened. Choose high quality China-made self-powered frozen refrigerating reefer, the lowest temperature is up to -5℃ to 15℃. And the reefer can be adjusted at the driver cab.
If you're interested in our refrigerated minivan, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of JMC TESHUN diesel refrigerated minivan manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of JMC teshun diesel engine refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
JMC teshun 4*2 LHD gasoline refrigerated minivan for sale |
| Drive Type |
4*2 LHD, |
| Payload (kg) |
0.80T-1.2T |
| Seating person |
3 |
| GVW (kg) |
3510 |
| Curb Weight (kg) |
2500 |
| Overall Dimensions (L*W*H) (mm) |
5652×1972×2450 |
| Insulation van dimension(L*W*H)(mm) |
2800×1610×1350 |
| Driver cab |
JMC teshun single cab |
| Engine |
Engine Model |
JX493ZLQ6 |
| Engine Brand |
jianglin |
| Fuel Type |
Diesel |
| Max output (hp/rpm) |
85KW/116hp |
| Emission Standard |
Euro Ⅵ |
| Capacity (cc) |
2771 |
| Chassis |
Chassis Brand |
jmc |
| Tire Specification |
225/65R16C *4 |
| Wheelbase (mm) |
3570 |
| Axle No. |
2 |
| Steering Wheel |
Left hand drive, |
| Gear Box |
5 speed gearbox, manual |
| Brake |
Air brake |
| Air-conditioner |
Yes, |
| Cold Room |
Box inner dimension(mm) |
2800×1610×1350 |
| Box Side |
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. |
| Box Floor |
Baseboard adopts aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. |
| Doors |
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc.
The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability.
Door edgings, door locks and accessories use stainless steel materials.
|
| Refrigeration unit |
Choose high quality China-made self-powered frozen refrigerating reefer, the lowest temperature is up to -5℃ to 15℃. And the reefer can be adjusted at the driver cab. |
| Remark |
1, stainless steel material pharmaceutical products ventilation slots;
2, temperature and humidity recorder with printing function and GPS (Global Positioning System);
3,Free to paint or Non-Adhesive label
|
|
|
JMC 4*2 LHD diesel engine refrigerated minivan for sale, good price new JMC cold refrigerated minibus for sale Images
|
